Slate URC8200

Slate provides a simplified control solution intended for hospitality applications.

Slate URC8200

Features & Benefits

Simplified Modeless Control

All keys on this remote are dedicated to controlling your cable box except for the POWER, VOLUME, and MUTE keys.

Secured Battery Compartment

This remote features a secure battery compartment to prevent battery theft.

IR Learning

This remote includes IR learning, making it possible to learn IR functions for TV models that may not be supported in the IR code library.

Backlit Keypad

This remote control features a backlit keypad, making it easier to read and use the remote while in a dark setting.

Fully Cleanable

Slate is designed to be cleaned with surface cleaners like sprays and wipes, creating a product that is free from germs for user peace of mind.

Slate URC8200

Remote Control Setup

Using Code Entry

Turn on your TV and follow the steps below to set up your remote.

Be sure to point the remote at your TV during setup.

1. Press and hold SETUP until the LED blinks twice

2. Press the TV POWER key.

3. Using the digit keys on the remote, enter the code shown in the code finder above.

4. Test the remote to confirm that it controls your TV as expected. If it does not, try again using the next code listed.

For Popular Brands

Turn on your TV and follow the steps below to set up your remote.

Be sure to point the remote at your TV during setup.

1. Press and hold SETUP until the LED blinks twice

2. Press the TV POWER key twice.

3. Find your TV brand in the charts below. Press and hold the corresponding digit key while aiming the remote at your TV.

4. Release the key when the TV turns off and setup is complete

Volume Lock

Slate defaults the volume controls to the TV. To change volume lock settings, perform the steps below.

1. Press and hold SETUP until the LED blinks twice

2. Press the TV POWER key twice.

3. Press VOL+ to lock volume controls to the TV. Press MUTE to lock volume controls to the cable box.

Learning Functions

To learn functions from another remote, do the following.

1. Press and hold SETUP until the LED blinks twice

2. Enter 9 – 7 – 5. The LED will blink twice.

3. Press the key to be learned on the Slate remote. The LED will begin flashing rapidly.

4. Hold the original remote and slate remotes nose-to-nose while pressing and holding down the key to be learned from the original remote. The LED on Slate will blink twice to confirm a key has been learned.

5. Repeat steps 3-4 for as many keys as needed.

6. Press and hold SETUP until the LED blinks twice to exit learning mode.

Programming a Macro

1. Press and hold SETUP until the LED blinks twice

2. Enter 9 – 9 – 5. The LED will blink twice.

3. Press the key that is to store the macro

4. Type out the macro sequence.

5. Press and hold SETUP until the LED blinks twice to confirm the macros has been saved.

Slate URC8200

Remote Functions

Key Functions

  • SETUP(unlabeled) used for remote control programming
  • TV POWER turns your TV on and off
  • CBL POWER(unlabeled) turns your cable box on and off
  • FF/PAUSE/PLAY/REW/STOP used to control playback On Demand programs
  • VOD used to access on demand program library
  • PAGE +/- cycles guide one page at a time
  • GUIDE displays program guide
  • MENU displays main cable menu
  • INFO displays information on current selected program
  • EXIT closes current menu
  • A-D KEYS used for special functions displayed on your cable menus
  • LAST returns to the previously selected channel
